Dell Vostro 3650 - Optical-Drive Assembly Installation

4. Perform the following steps to remove the optical-drive bracket:
a. Remove the screws that secure the optical-drive bracket to the optical drive.
b. Remove the optical-drive bracket from the optical drive.
Installing the Optical-Drive Assembly
1. Place the optical-drive bracket on the optical drive.
2. Tighten the screws to secure the optical-drive bracket to the optical drive.
3. Push the optical-drive assembly into the optical-drive bay until it snaps into place.
4. Tighten the screw to secure the optical drive to the computer.
5. Open the front-bezel door.
6. Connect the data cable and power cable to their connectors on the optical-drive assembly.
7. Close the front-bezel door.
8. Install the:
• bezel
• cover
9. Follow the procedures in After Working Inside Your Computer.
