Dell Vostro 3650 - System Fan Removal; System Fan Installation

c. Slide the system fan to remove it from the computer [3].
Installing the System Fan
1. Place the system fan on the computer.
2. Tighten the screws to secure the system fan to the computer.
3. Connect the system-fan cable to the connector on the system board.
4. Close the front-bezel door.
5. Install the:
a. bezel
b. cover
6. Follow the procedures in After Working Inside Your Computer.
Removing the System Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the:
• cover
• bezel
3. Open the front-bezel door.
4. Remove the:
• heatsink module
• processor
• expansion card
• memory
• WLAN card
5. Disconnect all the cables from the connectors on the system board.
6. Perform the following steps to remove the system board from the computer:
a. Remove the screws that secure the system board to the computer [1].
b. Slide and lift the system board to remove it from the computer [2].
20
