Front panel Two USB 3.0 connectors
Back panel Four USB 2.0 connectors
Video
• one 15-hole VGA connector
• one 19-pin HDMI connector
Memory-card reader one
Table 19. Control Lights And Diagnostic Lights
power button light white light — solid white light indicates power-on
state ; blinking white light indicates sleep/stand-by
state of the computer.
amber light — solid amber light indicates boot failure
- System Power Error; blinking amber light indicates
boot failure - System Power OK
drive activity light white light — blinking white light indicates that the
computer is reading data from, or writing data to the
hard drive.
Table 20. Power
Coin-cell battery 3 V CR2032 lithium coin cell
Input voltage 200-240 VAC / 100-127/200-240 VAC / 100-240
VAC
Input frequency 50 Hz to 60 Hz
Wattage 240 W
Input current 2 A / 7/3.5A / 4 A
Maximum heat dissipation 1024 BTU/hr
NOTE: Heat dissipation is calculated by using the power supply wattage rating.
Table 21. Physical
Height 380 mm (14.96 inches)
Width 175 mm (6.88 inches)
Depth 436.3 mm (17.17 inches)
Weight (Minimum) 8.5 kg (18.73 lb)
Table 22. Environmental
Temperature:
Operating 10 °C to 35 °C (50 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
35
