Dell XPS 630i - Installing a CD;DVD Drive

64 Drives
5 Slide the drive-release latch towards the base of the computer to release
the shoulder screw, and then slide the CD/DVD drive out of the drive bay.
6 Replace the drive panel (see "Installing the Drive Panel" on page 54).
7 Replace the computer cover (see "Replacing the Computer Cover" on
page 119).
NOTICE: To connect a network cable, first plug the cable into the network port or
device and then plug it into the computer.
8 Connect your computer and devices to electrical outlets, and then turn
them on.
Installing a CD/DVD Drive
1 Follow the procedures in "Before You Begin" on page 9.
2 Remove the computer cover (see "Removing the Computer Cover" on
page 13).
1 drive-release latch 2 shoulder screws (3)
3 CD/DVD drive
1
3
2
