Processor Heatsink 81
4
Tighten the four captive screws.
5
Connect the fan cable to the FAN_CPU connector on the system board
(see "System Board Components" on page 16).
6
Close the computer cover (see "Replacing the Computer Cover" on
page 119).
NOTICE: To connect a network cable, first plug the cable into the network port or
device and then plug it into the computer.
7
Connect your computer and devices to electrical outlets, and then turn
them on.
book.book Page 81 Monday, January 7, 2008 2:53 PM
