PMAC-PCI Hardware Reference
PMAC-PCI E-Point Jumper Descriptions 21
E54 - E65: Host Interrupt Signal Select
E Point and
Physical Layout
Location
Description
Default
E58
B7
Jump pin 1 to 2 to allow MI2 to interrupt host-
PC at PMAC interrupt level IR6.
No jumper
installed
E59
B7
Jump pin 1 to 2 to allow AXIS EXPANSION
INT-0 to interrupt host-PC at PMAC interrupt
level IR6.
No jumper
installed
E60
B7
Jump pin 1 to 2 to allow EQU6 to interrupt
host-PC at PMAC interrupt level IR6.
No jumper
installed
E61
B7
Jump pin 1 to 2 to allow EQU2 to interrupt
host-PC at PMAC interrupt level IR6.
No jumper
installed
E62
B6
Jump pin 1 to 2 to allow MI1 to interrupt host-
PC at PMAC interrupt level IR5.
No jumper
installed
E63
B6
Jump pin 1 to 2 to allow AXIS EXPANSION
INT-1 to interrupt host-PC at PMAC interrupt
level IR5.
No jumper
installed
E64
B6
Jump pin 1 to 2 to allow EQU5 to interrupt
host-PC at PMAC interrupt level IR5.
No jumper
installed
E65
B6
Jump pin 1 to 2 to allow EQU1 to interrupt
host-PC at PMAC interrupt level IR5.
No jumper
installed
E72 - E73: Panel Analog time Base Signal Enable
E Point and
Physical Layout
Location
Description
Default
E72
B9
Jump pin 1 to 2 to allow V to F converter
FOUT derived from wiper input on J2 to
connect to CHA4.
No jumper
installed
E73
B9
Jump pin 1 to 2 to allow V to F converter
FOUT/ derived from wiper input on J2 to
connect to CHA4/.
No jumper
installed
Note: With these jumpers ON, no encoder should be wired into ENC4 on JMACH1. E27 must connect
pins 1 to 2 because these are single-ended inputs. Variable I915 should be set to 4 to create a positive
voltage (frequency) number in PMAC.
