PMAC-PC Hardware Reference
PMAC-PCI Base Board Connector Pinouts 47
J5: I/O Port Connector
J5 JOPT (34-Pin Connector)
Front View
Pin #
Symbol
Function
Description
Notes
1
MI8
Input
Machine input 8
Low is TRUE
2
GND
Common
PMAC common
3
MI7
Input
Machine input 7
Low is TRUE
4
GND
Common
PMAC common
5
MI6
Input
Machine input 6
Low is TRUE
6
GND
Common
PMAC common
7
MI5
Input
Machine input 5
Low is TRUE
8
GND
Common
PMAC common
9
MI4
Input
Machine input 4
Low is TRUE
10
GND
Common
PMAC common
11
MI3
Input
Machine input 3
Low is TRUE
12
GND
Common
PMAC common
13
MI2
Input
Machine input 2
Low is TRUE
14
GND
Common
PMAC common
15
MI1
Input
Machine input 1
Low is TRUE
16
GND
Common
PMAC common
17
MO8
Output
Machine output 8
Low-TRUE (sinking);
High-TRUE (sourcing)
18
GND
Common
PMAC common
19
MO7
Output
Machine output 7
" "
20
GND
Common
PMAC common
21
MO6
Output
Machine output 6
" "
22
GND
Common
PMAC common
23
MO5
Output
Machine output 5
" "
24
GND
Common
PMAC common
25
MO4
Output
Machine output 4
" "
26
GND
Common
PMAC common
27
MO3
Output
Machine output 3
" "
28
GND
Common
PMAC common
29
MO2
Output
Machine output 2
" "
30
GND
Common
PMAC common
31
MO1
Output
Machine output 1
" "
32
GND
Common
PMAC common
33
+V
Input/
Output
+V power I/O
+V = +5V to +24V
+5V out from PMAC, +5 to +24V in
from external source, diode, isolation
from PMAC
34
GND
Common
PMAC common
This connector provides means for eight general-purpose inputs and eight general-purpose outputs. Inputs and
outputs may be configured to accept or provide either +5V or +24V signals. Outputs can be made sourcing
with an IC (U13 to UDN2981) and jumper (E1 & E2) change. E7 controls whether the inputs are pulled up or
down internally. Outputs are rated at 100mA per channel.
