Group 9 Communication Parameters
Parameters Functions Settings
Factory
Setting
Customer
a
09-00 Communication Address 01-254
00:Disable
01
a
09-01 Transmission Speed (Baud
Rate)
00: Baud rate 4800
01: Baud rate 9600
02: Baud rate 19200
03: Baud rate 38400
01
a
09-02 Transmission Fault Treatment 00: Warn and keep operating
01: Warn and RAMP to stop
02: Warn and COAST to stop
03: No warning and no
display
03
09-03 Over Time Detection during
Transmission
00: Disable
01: Enable
00
09-04 Communication Format 00: 7-bit for ASCII
01: 8-bit for ASCII
02: 8-bit for RTU
00
09-05 Even/Odd Parity and Stopping
Parity Setting
00: None parity + 2 stop bit
01: Even parity + 2 stop bit
02: Odd parity + 2 stop bit
03: None parity + 1 stop bit
04: Even parity + 1 stop bit
05: Odd parity + 1 stop bit
00
a
09-06 Communication Operation
Command 1
Bit0~1: 00: Disable
01: Stop
10: Start-up
11: JOG start-up
Bit2~3: Reserved
Bit4~5: 00: No function
01: FWD command
10: REV command
11: Change direction
command
Bit6~7: 00: 1
st
step
accel/decel speed
01: 2
nd
step
accel/decel speed
10: 3
rd
step
accel/decel speed
11: 4
th
step
accel/decel speed
00
