B
VFD-F Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
B-9
Remove any paint on metal saddle for good ground contact with
the plate and shielding.
saddle
the plate with grounding
Saddle on both ends
Saddle on one end
