VFD-F Series

DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED

B-17

PCB-SUPPORT

PCB-SUPPORT

CONTROL-BOARD

PCB-SUPPORT

INSULATOR

RELAY-CARD

SCREW M3*P0.5

TORQUE=2~4Kgf-cm

PCB-SUPPORT

SCREW M3*P0.5

TORQUE=2~4Kgf-cm

CONTROL-BOARD

RELAY-CARD

INSULATOR
