Chapter 1 Unpacking Check and Model Explanation|ASDA-A&A+ Series
1-8 Revision April 2009
ASDA-A+ Series Servo Drive
Servo drive Servo motor
ECMA-F21830S
ECMA-E21835S
4500W ASD-A4523-B
ECMA-F21845S
5500W ASD-A5523-B ECMA-F218553
7500W ASD-A7523-B ECMA-F218753
The drives shown in the above table are designed for use in combination with the specific servo motors.
Check the specifications of the drives and motors you want to use.
Also, please ensure that both the servo drive and motor are correctly matched for size (power rating). If the
power of motor and drive is not within the specifications, the drive and motor may overheat and servo alarm
would be activated. For the detail specifications of servo drives and motors, please refer to Chapter 11
“Specifications”.
The drives shown in the above table are designed according to the three multiple of rated current of motors
shown in the above table. If the drives which are designed according to the six multiple of rated current of
motors are needed, please contact our distributors or your local Delta sales representative.
