Appendix A Accessories|ASDA-A&A+ Series
A-8
Revision April 2009
Encoder Cables
Delta Part Number: ASD-CAEN0003, ASD-CAEN0005
(1.3 inch) (0.787 inch)
L
(32 mm)
(20 mm)
L
Title Part No.
mm inch
1 ASD-CAEN0003
3000 ± 10 118 ± 0.4
2 ASD-CAEN0005
5000 ± 10 197 ± 0.4
Delta Part Number: ASD-CAEN1003, ASD-CAEN1005
L
L
Title Part No. Straight
mm inch
1 ASD-CAEN1003 MS 3106-20-29S
3000 ± 10 118 ± 0.4
2 ASD-CAEN1005 MS 3106-20-29S
5000 ± 10 197 ± 0.4
I/O Signal Connector (CN1)
Delta Part Number: ASD-CNSC0050
Vendor Name Vendor P/N
3M TAIWAN LTD 10150-3000PE
3M TAIWAN LTD 10350-52A0-008
