Appendix B Accessories|ASDA-A&A+ Series
B-2
Revision April 2009
AC Servo Drive - EMI Filter Cross Reference
ASDA-A Series Servo Drive
Item Power Servo Drive Model Recommended EMI Filter FootPrint
16DRT1W3S（1-phase）
N
1 100W ASD-A0121LA
10TDT1W4C（3-phase）
N
16DRT1W3S（1-phase）
N
2 200W ASD-A0221LA
10TDT1W4C（3-phase）
N
16DRT1W3S（1-phase）
N
3 400W ASD-A0421LA
10TDT1W4C（3-phase）
N
16DRT1W3S（1-phase）
N
4 750W ASD-A0721LA
10TDT1W4C（3-phase）
N
16DRT1W3S（1-phase）
N
5 1000W ASD-A1021LA
10TDT1W4C（3-phase）
N
16DRT1W3S（1-phase）
N
6 1500W ASD-A1521MA
10TDT1W4C（3-phase）
N
7 2000W ASD-A2023LA
26TDT1W4C（3-phase）
N
8 2000W ASD-A2023MA
26TDT1W4C（3-phase）
N
9 3000W ASD-A3023LA
26TDT1W4C（3-phase）
N
10 3000W ASD-A3023MA
26TDT1W4C（3-phase）
N
ASDA-A+ Series Servo Drive
Item Power Servo Drive Model Recommended EMI Filter FootPrint
1 4500W ASD-A4523-B
20TDT1W4D（3-phase）
N
2 5500W ASD-A5523-B
RF075M43BA（3-phase）
Y
3 7500W ASD-A7523-B
RF075M43BA（3-phase）
Y
Installation
All electrical equipment, including AC servo drives, will generate high-frequency/low-frequency noise and will
interfere with peripheral equipment by radiation or conduction when in operation. By using an EMI filter with
correct installation, much of the interference can be eliminated. It is recommended to use Delta’s EMI filter to
have the best interference elimination performance.
We assure that it can comply with following rules when AC servo drive and EMI filter are installed and wired
according to user manual:
EN61000-6-4 (2001)
EN61800-3 (2004) PDS of category C2
EN55011+A2 (2007) Class A Group 1
