Preface|ASDA-A&A+ Series
iv
Revision April 2009
Main Circuit Terminal Wiring
¾ Please perform the wiring after the terminal blocks are all removed from the drive.
¾ Insert only one wire into one terminal on the terminal block.
¾ When inserting wires, please ensure that the conductors are not shorted to adjacent terminals or wires.
¾ Ensure to double check the wiring before applying power to the drive.
¾ If the wiring is in error, perform the wiring again with proper tools. Never use force to remove the terminals or wires. Otherwise,
it may result in malfunction or damage.
NOTE
1) In this manual, actual measured values are in metric units. Dimensions in (imperial
units) are for reference only. Please use metric for precise measurements.
2) The content of this manual may be revised without prior notice. Please consult our
distributors or download the most updated version at
http://www.delta.com.tw/industrialautomation
.
.
