Delta Electronics Elevator Drive VFD-VL - B.6 DC Choke Recommended Values

Revision Nov. 2008, VLE1, SW V1.03 B-16
B.6 DC Choke Recommended Values
230V DC Choke
Input voltage kW HP DC Amps Inductance (mh)
5.5 7.5 32 0.85
7.5 10 40 0.75
11 15 62 Built-in
15 20 92 Built-in
18.5 25 110 Built-in
22 30 125 Built-in
30
40 - Built-in
230Vac
50/60Hz
3-Phase
37
50 - Built-in
460V DC Choke
Input voltage kW HP DC Amps Inductance (mh)
5.5 7.5 18 3.75
7.5 10 25 4.00
11 15 32 Built-in
15 20 50 Built-in
18.5 25 62 Built-in
22 30 80 Built-in
30
40 92 Built-in
37
50 110 Built-in
45
60 125 Built-in
55
75 200 Built-in
460Vac
50/60Hz
3-Phase
75
100 240 Built-in
