Appendix B Accessories|
Revision Nov. 2008, VLE1, SW V1.03 B-21
B.7.3 Dimension of the Digital Keypad
Unit: mm [inch]
B.7.4 Recommended Position the Rubber Magnet of the Digital
Keypad
This rubber magnet is shipped with the digital keypad. Users can adhere to anywhere of
the back of the digital keypad to stick on the case of the AC motor drive. Please don’t stick
on the communication port to prevent reducing magnetic force.
LABEL
JOG
FWD
REV
RUN
PU
STO P
RESET
PROG
DATA
MODE
789
654
12
0
.
3
+/ -
KPV L-C C0 1
PUEX TRE VFW DJO GSTOPRU N
rubber
magnet
rubber
magnet
