9
CONNECTING BAND SAW TO POWER SOURCE
POWER CONNECTIONS
A separate electrical circuit should be used for your tools. This circuit should not be less than #12
wire and should be protected with a 20 Amp fuse. Have a certified electrician replace or repair a
worn cord immediately. Before connecting the motor to a power line, make sure the switch is in
the “OFF” position and be sure that the electric current is of the same characteristics as stamped
on the motor nameplate. Running on low voltage will damage the motor.
WARNING: DO NOT EXPOSE THE TOOL TO RAIN OR OPERATE THE TOOL IN DAMP LO-
CATIONS.
In the event of a malfunction or breakdown, grounding
provides a path of least resistance for electric current to
reduce the risk of electric shock. This tool is equipped
with an electric cord having an equipment-grounding
conductor and a grounding plug. The plug must be
plugged into a matching outlet that is properly installed
and grounded in accordance with all local codes and
ordinances.
Do not modify the plug provided - if it will not fit the
outlet, have the proper outlet installed by a qualified
electrician.
Improper connection of the equipment-grounding con-
ductor can result in risk of electric shock. The conductor
with insulation having an outer surface that is green with
or without yellow stripes is the equipment-grounding
conductor. If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment
grounding conductor to a live terminal.
Check with a qualified electrician or service personnel if
the grounding instructions are not completely
understood, or if in doubt as to whether the tool is
properly grounded.
GROUNDING INSTRUCTIONS
CAUTION: THIS TOOL MUST BE GROUNDED WHILE IN USE
TO PROTECT THE OPERATOR FROM ELECTRIC SHOCK.
Use only 3-wire extension cords that have 3-prong
grounding type plugs and 3-hole receptacles that accept
the tool's plug, as shown in Fig. 13.
Repair or replace damaged or worn cord immediately.
This tool is intended for use on a circuit that has an outlet
and a plug that looks like the one shown in Fig. 13.
A temporary adapter, which looks like the adapter illus-
trated in Fig. 14, may be used to connect this plug to a
2-pole receptacle, as shown in Fig. 14, if a properly
grounded outlet is not available. The temporary adapter
should be used only until a properly grounded outlet can
be installed by a qualified electrician. THIS ADAPTER IS
NOT APPLICABLE IN CANADA. The green-colored
rigid ear, lug, and the like, extending from the adapter
must be connected to a permanent ground, such as a
properly grounded outlet box, as shown in Fig. 14.
CAUTION: IN ALL CASES, MAKE CERTAIN THE RE-
CEPTACLE IN QUESTION IS PROPERLY GROUNDED.
IF YOU ARE NOT SURE HAVE A CERTIFIED ELEC-
TRICIAN CHECK THE RECEPTACLE.
Fig. 14Fig. 13
GROUNDED OUTLET BOX
CURRENT
CARRYING
PRONGS
GROUNDING BLADE IS
LONGEST OF THE 3 BLADES
GROUNDED OUTLET BOX
GROUNDING MEANS
ADAPTER
