5
30
37
38
36
39
32
35
31
33
34
Fig. 4
30 - Leg (4)
31 - 3/8” Flat Washer for Mounting Saw to Stand & for Assembling Stand (24)
32 - Foot (4)
33 - M8 Hex Nut for Mounting Saw to Stand & for Assembling Stand (20)
34 - M8 x 40mm Hex Screw for Mounting Saw to Stand (4)
35 - M8 x 20mm Carriage Bolts for Assembling Stand (16)
36 - 18-1/2” Top Front and Rear Brackets (2)
37 - 17” Top Side Brackets (2)
38 - 22” Bottom Front and Rear Brackets (2)
39 - 20-3/8” Bottom Side Brackets (2)

Delta 36-540 Specifications

General

No-Load Speed	5000 rpm
Blade Diameter	10 inches
Max Rip Capacity	30 inches
Arbor Size	5/8 inches
Maximum Rip Capacity Right	30 inches
Maximum Rip Capacity Left	12 in
Maximum Depth of Cut at 45 Degrees	2-1/4 in
Max Cut Depth at 45°	2-1/4 in
Table Size	20 x 26 inches
