AS Series Operation Manual
4-4
The completed baffle installation is shown below.
4.1.2 Installing a Removable Terminal Block
Install the removable terminal block on the module as shown below.
Installation
1. Align the terminal block at the printed circuit board, and press it into the module.
Removal
1. Pull the clips down in the direction shown by the arrow, and then pull the terminal block up
