Chapter 9 Ethernet Specification and Operation
9-97
9.10 Operation and Monitor on the Web
9.10.1 Getting Started
You can enter AS Series PLC IP address in the search bar of your browser to connect to your device. After that you can
set up and monitor AS Series PLC.
9.10.1.1 Exploring the webpage
After connected to the module, you can see the AS300 webpage with 5 sections as the image shown below.
Descriptions:
Section Contents
Banner
Delta logo and the name of the connected device
Login
Username and password
Menu
Sitemap is shown in tree diagram.
(The menu shows data based on the permission of the current
user.)
Context
Main contents; click an item on the menu section, its content
appears here.
Bottom
Copyright information and Delta webpage information
