Chapter 9 Ethernet Specification and Operation

9-87

Instance

Attribute

Name

Access

Rule

Data Type Values Description

H’00 X0.0 Get BOOL H’00 X0.0 bit register

H’01 X0.1 Get BOOL H’00 X0.1 bit register

H’02-H’03FE X0.2-X63.14 Get BOOL H’00 X0.2 -X63.14 bit register

H’3FF X63.15 Get BOOL H’00 X63.15 bit register

 When Instance = 2, the Instance Attributes are listed below.

Instance

Attribute

Name

Access

Rule

Data Type Values Description

H’00 X0 Get INT H’00 X0 word register

H’01 X1 Get INT H’00 X1 word register

H’02-H’3E X2-X62 Get INT H’00 X2-X62 word register

H’3F X63 Get INT H’00 X63 word register

9.8.11 Y Register (Class ID: 351 Hex)

 Service Code

Service Code Service Name

Support

Description

Class Attribute

Instance

Attribute

H’0E Get_Attribute_Single X V Read one attribute

H’10 Set_Attribute_Single X V Write one attribute

H’32 Read_Parameter X V Read Parameter

H’33 Write_Parameter X V Write Parameter

 Class

 Class ID：H’351

 Instance

 H’01：Instance Attribute, Bit Register

 H’02：Instance Attribute, Word Register

Delta AS16AP11P-A User Manual
