AS Series Operation Manual
1-4
_1
Classification Model Name Description
(8DI+6DO+2AI+2AO) and up to 1024 I/Os. Program
capacity: 64K steps, removable terminal blocks
AS218TX-A
CPU module, NPN output, 1x Ethernet port , 2x RS-485
ports, 1x USB port, 1x Micro SD interface, CAN
communication port, supporting 18 I/Os
(8DI+6DO+2AI+2AO) and up to 1024 I/Os. Program
capacity: 64K steps, removable terminal blocks
AS218RX-A
CPU module, Relay output, 1x Ethernet port , 2x RS-485
ports, 1x USB port, 1x Micro SD interface, CAN
communication port, supporting 18 I/Os
(8DI+6DO+2AI+2AO) and up to 1024 I/Os. Program
capacity: 64K steps, removable terminal blocks
Digital
input/output
module
AS08AM10N-A
24VDC
5mA
8 inputs
Spring-clamp terminal block
AS08AN01P-A
5 - 30VDC
0.5A/output, 4A/COM
8 outputs
Sourcing output
Spring-clamp terminal block
AS08AN01R-A
240VAC/24VDC
2A/output, 8A/COM
8 outputs
Relay
Spring-clamp terminal block
AS08AN01T-A
5 - 30VDC
0.5A/output, 4A/COM
8 outputs
Sinking output
Spring-clamp terminal block
AS16AM10N-A
24VDC
5mA
