Delta AS16AP11P-A User Manual

AS Series Operation Manual
10-40
_10
Index Subindex Object name Data type Attribute
Default
value
H’1403
--
RxPDO4 communication
parameter
H’00 Number of valid subindex Unsigned 8 bits R 3
H’01 COB-ID of RxPDO4 Unsigned 32 bits RW 0x80000000
H’02 Transmission mode Unsigned 8 bits RW 0xFF
H’03 Inhibit time Unsigned 16 bits RW 0
H’1404
--
RxPDO5 communication
parameter
H’00 Number of valid subindex Unsigned 8 bits R 3
H’01 COB-ID of RxPDO5 Unsigned 32 bits RW 0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
0
H’1405
--
RxPDO6 communication
parameter
H’00 Number of valid subindex Unsigned 8 bits R 3
H’01 COB-ID of RxPDO6 Unsigned 32 bits RW 0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
0
H’1406
--
RxPDO7 communication
parameter
H’00 Number of valid subindex Unsigned 8 bits R 3
H’01 COB-ID of RxPDO7 Unsigned 32 bits RW 0x80000000
H’02 Transmission mode Unsigned 8 bits RW 0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
0
H’1407
--
RxPDO8 communication
parameter
H’00 Number of valid subindex Unsigned 8 bits R 3
H’01 COB-ID of RxPDO8 Unsigned 32 bits RW 0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
0
H’1600 -- RxPDO1 mapping parameter
H’1600
H’00
Number of valid subindex
Unsigned 8 bits
RW
4
H’01 The first mapped object Unsigned 32 bits RW 0x20000110
