AS Series Operation Manual
12-22
_12
IO-Link
Event
Codes
Type
Event Solution
Source
Warning Error
Notifica-
tion
IO-Link
Master
IO-Link
Device
16#6320 V Parameter error
Check device
specificaitons
V
16#6321 V Parameter missing
Check device
specifications
V
16#7710
V
Device short circuit
Check installation
V
16#8C10 V
Process variable range
over-run
Check process data V
16#8C20 V
Measurement range over-
run
Check application V
16#8C30 V
Process variable range
under-run
Check process data V
16#8CA0 V
No connected IO-Link
device
Check installation V
16#8CA1 V
The version of the IO-Link
protocol is different from
the one configured.
Use matching IODD file
and configured again.
V
16#8CA2 V
Connected device is
different from the one
configured in the software
Check configurations and
installation
V
16#8CA3 Reserved V
16#8CA4 V
IO-Link device process
cable short circuit
Check installation V
16#8CA5 V
Master temperature
exceeds 135°C
Clear source of heat V
16#8CA6 V
Master temperature
exceeds 160°C
Clear source of heat and
lower load
V
16#8CA7 V
Device power supply
voltage under-run L+
(<18V)
Check the external power
supply V
16#8CA8 V
Device power supply
voltage under-run L+ (<9V)
Check the external power
supply
V
16#8CA9 V Illegal device ID
Check device
specifications
V
16#8CAA V
IO-Link process data
range over-run
Check device
specifications
V
16#8CAB V
Process data range over-
run
Scan the device and
download the configuration
again
V
16#8CAC
V
Data storage error
Contact the factory
V
0xFF21 V New connected device V
0xFF22 V Device disconnected Check installation V
0xFF23 V
Data storage identification
mismatch
Set the Data Storage
access locked and set it to
backup / restore and then
backing up data according
to actual placement.
V
