Chapter 12 Troubleshooting
12-35
12.4.9
Error Codes and LED Indicators for Module AS01DNET
(Master/Slave Mode)
Code Explanation Correction
0~63
Node address of AS01DNET-A
(in normal operation)
--
AS01DNET-A is in STOP status.
Turn the PLC to RUN and start I/O data exchange
F0
The node ID of AS01DNET is the
same as that of other node or
exceeds the allowed range.
1. Ensure that the node address of AS01DNET is unique.
2. Re-power AS01DNET.
F1 No configured slave in Scan List.
Configure the scan list and then download the configuration to
AS01DNET.
F2
Too low voltage of the work
power
Check if the power supply for AS01DNET and the PLC is normal.
F3 AS01DNET enters the test mode
Switch the function switch IN1 from On to Off and re-power
AS01DNET-A.
F4 BUS-OFF
1. Check if the network cable is normal
and the shielded cable is
grounded.
2. Check if the baud rates of all nodes in the network are same.
3. Check if the start and end of the network cable are both connected
with a 121Ω terminal resistor.
4. Re-power AS01DNET-A.
F5 No network power
1. Check if the network cable is normal.
2. Ensure that the network power is normal.
F6
Internal error; Flash or RAM
check error
If the error still exists after re-power, send AS01DNET-A back to the
factory for repair.
F8
Error produced in factory
manufacturing
If the error still exists after re-power, send AS01DNET-A back to the
factory for repair.
F9
Internal error; EEPROM access
failure
If the error still exists after re-power, send AS01DNET-A back to the
factory for repair.
FA Invalid configuration data
1. Configure the network correctly and re-download it to AS01DNET-
A.
2. Check if the node address of one slave in the scan list is the same
as that of AS01DNET-A.
E0
Identification parameters returned
from the slave do not match the
configuration data.
1. Check if there is any change in node ID of the slave in the
network.
2. Check if some node device in the network is replaced.
3. Re-configure the network.
E1
I/O Data size returned does not
match that in the scan list.
Re-configure I/O data size of the slave, download the configuration to
AS01DNET-A and run the PLC.
E2
The slave device in the scan list
does not exist or is offline when
AS01DNET-A is in master mode.
1. Check if there is a change in the node address of the slave.
2. Check if the communication cable is disconnected or connected
loosely.
3. Check if the bus cable length exceeds the maximum transmission
distance. If so, the system may not be stable.
The I/O connection between the
slave AS01DNET-A and the
master is broken when
AS01DNET-A is in slave mode.
E3
AS01DNET-A fails to transmit
data.
1. Make sure that the connection between AS01DNET-A and the
network is normal.
