Chapter 2 Specifications and System Configuration
2-38
2_
Analog-to-Digital
Conversion
Current Input
Rated Input Range
±20 mA
0 mA20 mA
4 mA–20 mA
Rated Conversion
Range
K-32000
~
K+2000
K0
~
K32000
K0
~
K32000
Hardware Input
Limit*
1
-20.24 mA ~ 20.24 mA -0.24 mA ~ 20.24 mA 3.81 mA ~ 20.19 mA
Conversion Limit*
2
K-32384
~
K32384
K-384
~
K32384
K-384
~
K32384
Error Rate
Room Temperature: ±0.2% ; Full Temperature Range: ±0.5%
Hardware R
esolution
16 bits
Input Impedance
250Ω
Absolute Input
Range*
3
±32 mA
*1: If the input signal exceeds the hardware input limit, the module only shows the maximum value. If the input
signal is below the lower limit, it only shows the minimum value.
*2: If the input signal exceeds the hardware input limit, it also exceeds the conversion limit and a conversion
limit error appears. For example in the voltage input mode (4 mA to 20 mA), when the input signal is 0 mA,
exceeding the hardware upper limit, it also exceeds the conversion upper limit. The module uses the upper
limit value (-384) as the input signal and a conversion limit error appears.
*3: If an input signal exceeds the absolute range, it might damage the channel.
Functional specifications for the digital-to-analog conversion
Digital-to-Analog
Conversion
Voltage Output
Rated Output Range
±10 V
0 ~ 10 V
±5 V
0 ~ 5 V 1 ~ 5 V
Conversion Range
K-32000
~
K32000
K0
~
K32000
K-32000
~
K32000
K0
~
K32000
K0
~
K32000
Hardware Output Range
-10.1 V
~
+10.1 V
-0.1 V
~
10.1 V
-5.05 V
~
+5.05 V
-0.05 V
~
+5.05 V
0.95
~
5.05 V
Error Rate
(Room Temperature)
±0.2%
Error Range
(Full temperature range)
±0.5%
Linearity Error
(Room Temperature)
±0.05%
Linearity Error
(Full Temperature Range)
±0.05%
Hardware Resolution
12 bits
Permissible load
impedance
1k Ω 500Ω
