Delta AS16AP11P-A User Manual

Chapter 2 Specifications and System Configuration
2-58
2_
Model
Item
Pulse input External input
Input impedance
4.7 kΩ
Input signal
Signal signal: 5 – 24 VDC (sinking or sourcing) ; differential signal: 5 V
Electrical isolation
Optocoupler
Input display
When the optocoupler is driven, the input LED indicator is ON.
Weight
138 g
Electrical specifications for the SSI input and output
Model
Item
SSI input SSI output
Number of inputs /
outputs
2 (DATA+/DATA-) 2 (CLK+/CLK-)
Connector type
D-sub 15
Voltage / Current
5 VDC, 1 mA
5 VDC, ±60 mA (max.)
Action
level
OFF→ON
V
ID
*1
≧
0.2V
-
ON→OFF
V
ID
≦
0.2V
-
Maximum input
frequency
1.25 MHz
Input impedance
12 kΩ (terminal resistor 120 Ω)
-
Input signal
RS-422
Electrical isolation
Optocoupler
Input display
When the optocoupler is driven, the input LED indicator is ON.
*1: V
ID
is the voltage difference between DATA+ and DATA-.
Electrical specifications for the external outputs
Model
Item
AS02HC-A
Number of outputs
4
Connector type
D-sub 15
Ouptut type
NPN transistor (sinking)
Voltage
5 – 30 VDC, 0.1 A
Maximum load
Resistance
0.1A/output
Inductance
-
Bulb
-
Maximum
output
frequency
*1
Resistance
10 kHz
Inductance
-
Bulb
-
Maximum
Response time
OFF→ON
25 μs
Electrical specifications for the +5 V encoder power supply
Model
Item
AS02HC-A
Number of outputs
2 (+5 VO/GND)
Connector type
D-sub 15
