Delta ASD-A2-2023 Series

ASDA-A2 Chapter 11 Specifications
11-44 Revision February, 2017
Motor Frame Size: 100 mm ~ 130 mm Models (Units: mm)
Model
F△1305□S
F△1308□S
F△1313□S
F△1318□S
G△1303□S
G△1306□S
G△1309□S
LC
130
130
130
130
130
130
130
LZ
9
9
9
9
9
9
9
LA
145
145
145
145
145
145
145
S
)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


LB
)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


LL
(without brake)
139.5
152.5
187.5
202.0
147.5
147.5
163.5
LL
(with brake)
168.0
181.0
216.0
230.7
183.5
183.5
198
LS
47
47
47
47
47
47
47
LR
55
55
55
55
55
55
55
LE
6
6
6
6
6
6
6
LG
11.5
11.5
11.5
11.5
11.5
11.5
11.5
LW
36
36
36
36
36
36
36
RH
18
18
18
18
18
18
18
WK
8
8
8
8
8
8
8
W
8
8
8
8
8
8
8
T
7
7
7
7
7
7
7
TP
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
NOTE
1) Dimensions are in millimeters. Actual measured values are in metric units.
2) Dimensions of the servo motor may be revised without prior notice.
3) The boxes () in the model names represent shaft end/brake or the number of oil seal.
4) Please refer to Chapter 1 for the boxes (△ ) in the model names (which represents encoder type).
