ASDA-A2 Appendix A Accessories
Revision February, 2017 A-9
Delta Part Number: ASD-CAPW3303, ASD-CAPW3305 (for motors with brake)
Item Part No. Straight
L L1
mm inch mm inch
1 ASD-CAPW3303 MS 3106-24-11S
3000100 118  4 3100100 122  4
2 ASD-CAPW3305 MS 3106-24-11S
5000100 197  4 5100100 201  4
 Encoder Connectors
Delta Part Number: ASD-ABEN0000
Delta Part Number: ASD-ABEN1000
