ASDA-A2 Chapter 2 Installation

2-6 Revision February, 2017

2.6 EMI Filter Selection

220V Series

Item Power Servo Drive Model

Recommended EMI Filter

FootPrint

1PH 3PH

1 100W ASD-A2-0121- RF007S21AA RF022B43AA N

2 200W ASD-A2-0221- RF007S21AA RF022B43AA N

3 400W ASD-A2-0421- RF007S21AA RF022B43AA N

4 750W ASD-A2-0721- RF007S21AA RF037B43BA N

5 1.0kW ASD-A2-1021- RF007S21AA RF037B43BA N

6 1.5kW ASD-A2-1521- RF007S21AA RF037B43BA N

7 2.0kW ASD-A2-2023- - RF037B43BA N

8 3.0kW ASD-A2-3023- - RF037B43BA N

9 4.5kW ASD-A2-4523- - RF075M43BA N

10 5.5kW ASD-A2-5523- - RF075M43BA Y

11 7.5kW ASD-A2-7523- - 30TDRT1W4 Y

12 11.0kW ASD-A2-1B23- - 50TDS4W4C -

13 15.0kW ASD-A2-1F23- - 50TDS4W4C -

400V Series

Item Power Servo Drive Model Recommended EMI Filter FootPrint

1 750W ASD-A2-0743- RF007S43AA N

2 1000W ASD-A2-1043- RF007S43AA N

3 1500W ASD-A2-1543- RF022B43AA N

4 2000W ASD-A2-2043- RF037B43BA N

5 3000W ASD-A2-3043- RF037B43BA N

6 4500W ASD-A2-4543- RF075M43BA N

7 5500W ASD-A2-5543- RF075M43BA Y

8 7500W ASD-A2-7543- RF075M43BA Y
