Delta ASD-B2-1521-B

Chapter 10 Specifications ASDA-B2
10-18 Revision May, 2018
ASD-B2-1021; ASD-B2L-1021; ASD-B2-1521 (1 kW ~ 1.5 kW)
SCREW: M4×0.7
MOUNTING SCREW TORQUE:14(kgf-cm)
70(2.76) 189.4(7.45)
Ø6(0.23)
GROUNDING
85.1(3.35)
74(2.91)
5(0.19)
WEIGHT
1.72 (3.79)
(1) Dimensions are in millimeters (inches); Weights are in kilograms (kg)
and (pounds (lbs)).
(2) Dimensions and weights of the servo drive may be revised without
prior notice.
NOTE
