Chapter 3 Wiring ASDA-B2

3-10 Revision May, 2018

Encoder Connection (Diagram 2)

NOTE

This diagram shows the connection between the servo drive and the

motor encoder. It is not drawn by the practical scale and specification

will be different according to the selected servo drive and motor model.

Please refer to section 3.4 CN2 Connector.
