Delta ASD-M-0721 Series User Manual

Chapter 8 Parameters ASDA-M
8-304 Revision December, 2014
Setting Value: 0x45
DI Name Function Description of Digital Input (DI)
Trigger
Method
Control
Mode
INHP
In position mode, when this DI is ON, the external pulse input
command is not working.
(Note: The function has to be set to DI6 so as to ignore the
pulse command)
Level
triggered
PT
Setting Value: 0x46
DI Name Function Description of Digital Input (DI)
Trigger
Method
Control
Mode
STOP Motor stops Rising
edge
triggered
PR
NOTE
1) 11~17 Single control mode; 18~20 Dual control mode.
2) When P2-10～P2-17 is set to 0, DI has no function.

Delta ASD-M-0721 Series Specifications

General

Brand	Delta
Model	ASD-M-0721 Series
Category	Servo Drives
Language	English
