CANopen Communication Module DVPCOPM-SL
(2)
Select ”Setup” => ”Communication Setting” => ”System Channel”, and the "Serial Port Setting” dialog box will
appear.
(3) Set up the communication parameters in the PC and DVP-SV, e.g. the communication port, address, baud rate
and communication format.
Item Function Default
COM Port
COM port on the PC to be used to communicate
with DVP-SV
COM1
Address Communication address of DVP-SV 1
Baud rate
Communication speed between the PC and
DVP-SV
9,600 (bps)
Data Bits 7
Parity Even Parity
Stop Bit
Communication protocol between the PC and
DVP-SV
1
Mode
Communication mode between the PC and
DVP-SV
ASCII
Click on “OK” and return to the main page.
DVP-PLC Operation Manual
15
