CANopen Communication Module DVPCOPM-SL
Hardware
connection:
DVPCOPM DVP28SV
RUN
STOP
Master
CANopen
DTA
RS-485
IFD9503
CAN+
CAN-
SHLD
GND
Node 1
Node 2
DTA4848
AT
SET
PV
SV
OUT ALM1 ALM2
°C
°
F
Software operation:
Add a master and slave to the CANopen Builder software as below.
DVP-PLC Operation Manual
36
