Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 8 Optional Cards  MS300 (IP66 / NEMA 4X)
8-17
 LED Indicator & Troubleshooting
There are two LED indicators on CMM-EIP01: POWER LED and LINK LED. POWER LED
displays the status of the working power, and LINK LED displays the connection status of the
communication.
LED Indicators
LED Status Indication Corrective Action
POWER Green
On Power supply in normal status No action is required.
Off No power supply
Check the power supply.
LINK Green
On
Network connection in normal
status
No action is required.
Flashes Network in operation
No action is required.
Off Network not connected
Check if the network cable is
connected.
Troubleshooting
Abnormality Cause Corrective Action
POWER LED off
The AC motor drive is not
powered.
Check if the AC motor drive is powered, and if the
power supply is normal.
The CMM-EIP01 is not
connected to the AC motor
drive.
Make sure the CMM-EIP01 is connected to the AC
motor drive.
LINK LED off
The CMM-EIP01 is not
connected to network.
Make sure the network cable is correctly connected
to network.
Poor contact to the RJ45
connector
Make sure the RJ45 connector is connected to the
EtherNet port.
No communication
card found
The CMM-EIP01 is not
connected to the network.
Make sure the CMM-EIP01 is connected to the
network.
The PC and the CMM-EIP01
are in different networks and
blocked by network firewall.
Search by IP or set up relevant settings using the
AC motor drive keypad.
Fail to open
CMC-EIP01 setup
page
The CMM-EIP01 is not
connected to the network.
Make sure the CMM-EIP01 is connected to the
network.
Incorrect communication
setting in DCISoft
Make sure the communication setting in DCISoft is
set to EtherNet.
The PC and the CMM-EIP01
are in different networks and
blocked by network firewall.
Set up with the AC motor drive keypad.
Able to open
CMC-EIP01 setup
page but fails to
utilize webpage
monitoring
Incorrect network setting in
the CMM-EIP01
Check if the network setting for the CMM-EIP01 is
correct. For the Intranet setting in your company,
please consult your IT staff. For the Internet setting
at home, please refer to the network setting
instruction provided by your ISP.
Fails to send e-mail
Incorrect network setting in
the CMM-EIP01
Check if the network setting for the CMM-EIP01 is
correct.
Incorrect mail server setting Confirm the IP address for the SMTP-Server.
