Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 7 Optional Accessories MS300 (IP66 / NEMA 4X)
7-9
230V, 50–60 Hz / One-Phase - Heavy Duty
Model
Rated
Current
ND / HD
[Arms]
Saturation
ND / HD
Current
[Arms]
AC Input /
Output
Reactor
Inductance
[mH]
AC Input
Reactor
Delta Part #
AC Output
Reactor
Delta Part #
DC
Reactor
Inductance
[mH]
DC Reactor
Delta Part #
VFD2A8MS21MNSAA
VFD2A8MS21MFSAA
2.8 5.6 5.857 DR005D0585
DR005L0254
5.857 DR005D0585
VFD4A8MS21MNSAA
VFD4A8MS21MFSAA
4.8 9.6 3.66 DR008D0366
DR005L0254
3.66 DR008D0366
VFD7A5MS21MNSAA
VFD7A5MS21MFSAA
7.5 15.0 2.662 DR011D0266
DR008L0159
2.662 DR011D0266
VFD11AMS21MNSAA
VFD11AMS21MFSAA
11.0 22.0 1.722 DR017D0172
DR011L0115
1.722 DR017D0172
230V, 50–60 Hz / Three-Phase - Normal Duty
Model
Rated
Current
ND / HD
[Arms]
Saturation
ND / HD
Current
[Arms]
AC Input /
Output
Reactor
Inductance
[mH]
AC Input
Reactor
Delta Part #
AC Output
Reactor
Delta Part #
DC
Reactor
Inductance
[mH]
DC Reactor
Delta Part #
VFD2A8MS23MNSAA 3.2 4.8 2.536 DR005A0254
DR005L0254
5.857 DR005D0585
VFD4A8MS23MNSAA
5.0 7.5 2.536 DR005A0254
DR005L0254
5.857 DR005D0585
VFD7A5MS23MNSAA 8.0 12.0 1.585 DR008A0159
DR008L0159
3.66 DR008D0366
VFD11AMS23MNSAA 12.5 18.75 0.746 DR017AP746
DR017LP746
2.662 DR011D0266
VFD17AMS23MNSAA
19.5 29.25 0.507 DR025AP507
DR025LP507
1.722 DR017D0172
VFD25AMS23MNSAA 27.0 40.5 0.32 DR033AP320
DR033LP320
1.172 DR025D0117
230V, 50–60 Hz / Three-Phase - Heavy Duty
Model
Rated
Current
ND / HD
[Arms]
Saturation
ND / HD
Current
[Arms]
AC Input /
Output
Reactor
Inductance
[mH]
AC Input
Reactor
Delta Part #
AC Output
Reactor
Delta Part #
DC
Reactor
Inductance
[mH]
DC Reactor
Delta Part #
VFD2A8MS23MNSAA 2.8 5.6 2.536 DR005A0254
DR005L0254
5.857 DR005D0585
VFD4A8MS23MNSAA
4.8 9.6 2.536 DR005A0254
DR005L0254
5.857 DR005D0585
VFD7A5MS23MNSAA 7.5 15.0 1.585 DR008A0159
DR008L0159
3.66 DR008D0366
VFD11AMS23MNSAA 11.0 22.0 1.152 DR011A0115
DR011L0115
2.662 DR011D0266
VFD17AMS23MNSAA
17.0 34.0 0.746 DR017AP746
DR017LP746
1.722 DR017D0172
VFD25AMS23MNSAA 25.0 50.0 0.507 DR025AP507
DR025LP507
1.172 DR025D0117

Delta Compact Drive MS300 IP66/NEMA 4X Series Specifications

General

Series	MS300
Category	DC Drives
IP Rating	IP66
NEMA Rating	NEMA 4X
Control Method	V/F, SVC
Communication Interface	RS-485
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Altitude	Up to 1000m
Vibration	1.0G
Input Voltage	Single/Three Phase 200-240V, Three Phase 380-480V
