Delta Compact Drive MS300 IP66/NEMA 4X Series User Manual

Chapter 8 Optional Cards  MS300 (IP66 / NEMA 4X)
8-8
Operation / Storage
Operation
: -10–50 °C (temperature), 90 % (humidity)
Storage: -25–70 °C (temperature), 95 % (humidity)
Shock / Vibration resistance
International standards
:
IEC 61800-5-1, IEC 60068-2-6 / IEC 61800-5-1, IEC 60068-2-27
 MS300 (IP66 / NEMA 4X) Communication Parameters when Connected to EtherNet
When you connect the MS300 (IP66 / NEMA 4X) to EtherNet, set up the communication parameters based
on the table below. The EtherNet master can read and write frequency command words and operation command
words for the MS300 (IP66 / NEMA 4X) after you set the communication parameters.
Parameter Function Current Set Value Definition of Parameter Values
00-20
Frequency command
source
8
The frequency command is controlled by
communication card.
00-21
Operation command
source
5
The operation command is controlled by
communication card.
09-30
Decoding method for
communication
0
Decoding method for the Delta AC motor
drive.
09-75
IP setting
0 Static IP(0) / Dynamic distribution IP(1)
09-76
IP address 1
192 IP address 192.168.1.5
09-77
IP address 2
168 IP address 192.168.1.5
09-78
IP address 3
1 IP address 192.168.1.5
09-79
IP address 4
5 IP address 192.168.1.5
09-80
Netmask 1
255 Netmask 255.255.255.0
09-81
Netmask 2
255 Netmask 255.255.255.0
09-82
Netmask 3
255 Netmask 255.255.255.0
09-83
Netmask 4
0 Netmask 255.255.255.0
09-84
Default gateway 1
192 Default gateway 192.168.1.1
09-85
Default gateway 2
168 Default gateway 192.168.1.1
09-86
Default gateway 3
1 Default gateway 192.168.1.1
09-87
Default gateway 4
1 Default gateway 192.168.1.1
 Basic Registers
BR#
R/W Content Set Value
#0 R Model name Defined by the system. The model code of CMM-MOD01=H’0103.
#1 R Firmware version
Displays the current firmware version in hex, e.g. H`0100 indicates
firmware version V1.00.
#2 R
Release date of the
version
Displays the date in decimal form. 10,000s digit and 1,000s digit are
for “month”; 100s digit and 10s digit are for “day”.
For 1 digit: 0 = AM; 1 = PM.
#11 R/W Modbus Time-out Pre-defined setting: 500 (ms)
#13 R/W Keep Alive Time Pre-defined setting: 30 (s)
 LED Indicator & Troubleshooting
LED Indicators
LED Status Indication Corrective Action
POWER
Green On Power supply in normal status No action is required
Green Off No power supply Check the power supply
