Chapter 8 Optional Cards MS300 (IP66 / NEMA 4X)
8-9
LED Status Indication Corrective Action
LINK Green
On
Network connection in normal
status
No action is required
Flashes Network in operation No action is required
Off Network not connected
Check if the network cable is
connected
Troubleshooting
Abnormality Cause Corrective Action
POWER LED off
AC motor drive not powered
Check if AC motor drive is powered, and if the power
supply is normal.
The CMM-MOD01 not
connected to AC motor drive
Make sure CMM-MOD01 is connected to AC motor
drive.
LINK LED off
Not connected to network
Make sure the network cable is correctly connected to
network.
Poor contact to RJ45 connector
Make sure the RJ45 connector is connected to EtherNet
port.
No module found
The CMM-MOD01 not
connected to network
Make sure the CMM-MOD01 is connected to the
network.
The PC and the CMM-MOD01
are in different networks and
blocked by network firewall.
Search by IP or set up the relevant settings using the
AC motor drive keypad.
Fails to open
CMM-MOD01
setup page
The CMM-MOD01 is not
connected to network
Make sure the CMM-MOD01 is connected to the
network.
Incorrect communication
setting in DCISoft
Make sure the communication setting in DCISoft is set
to EtherNet.
The PC and the CMM-MOD01
are in different networks and
blocked by network firewall.
Set up with the AC motor drive keypad.
Able to open
CMM-MOD01
setup page but
fails to utilize
webpage
monitoring
Incorrect network setting in
the CMM-MOD01
Check if the network setting for the CMM-MOD01 is
correct. For the Intranet setting in your company, please
consult your IT staff. For the Internet setting at home,
please refer to the network setting instruction provided
by your ISP.
Fails to send
e-mail
Incorrect network setting in the
CMM-MOD01
Check if the network setting for the CMM-MOD01 is
correct.
Incorrect mail server setting Confirm the IP address for the SMTP-Server.
To Next Page
