Delta DTK Series User Manual

2
 Ordering Information
DTK 1 2 3 4 5 6 7
Series DTK: Delta DTK Series Temperature Controller
Panel Size (W×H)
4848：4848 1/16 DIN W48 × H48mm
7272：7272 W72 × H72mm
4896：4896 1/8 DIN W48 × H96mm
9696：9696 1/4 DIN W96 × H96mm
Output options
R: Relay output, 250 VAC, 8A
V: Voltage pulse output 12VDC +/-15%
C: DC current output, 4 ~ 20 mA
Communication option
0: None
1: RS485 communication
Alarm option
0: None
1: 1 alarm output
2: 2 alarm output
 Specifications
Input Voltage AC 100 ~ 240 V, 50/60 Hz
Power Consumption 5VA max.
Display Method LCD display.Process value (PV): Red color, Set point (SV): Green color
Sensor Type
Thermocouple: K, J, T, E, N, R, S, B, L, U, TXK
3-wire Platinum RTD: Pt100, JPt100
Resistance: Cu50, Ni120
Control Mode PID, manual, and ON/OFF
Control Output
Relay output: Max. load 250VAC, 5A resistive load
Voltage pulse output: DC 12V, Max. output current 40 mA
Current output: DC 4 ~ 20 mA output (Load resistance: Max. 600Ω)
Alarm Output Type Relay output: Max. load 250VAC, 5A resistive load
Display Accuracy 0 or 1 digit to the right of the decimal point (selectable)
Sampling Rate Thermocouple or platinum resistor: 0.1 sec
Vibration Resistance 10 to 55 Hz, 10 m/s2 for 10 min, each in X, Y, and Z directions
Shock Resistance Max. 300 m/s2, 3 times in each of 3 axes, 6 directions
Ambient Temperature 0°C ~ +50°C
Storage Temperature -20°C ~ +65°C
Altitude Max. 2000 m
Relative Humidity 35% ~ 80% RH (non-condensing)
 Operation
 There are three modes of operation: operation, regulation, and initial setting. When power is applied, controller gets into the operation
mode. Press the
key to switch to regulation mode. If the key is pressed for more than 3 seconds, controller will switch to
the initial setting mode. Pressing the
key while in the regulation mode or initial setting mode forces the controller to return to the
operation mode.
 PV/SV: Sets the temperature set point and displays the temperature process value. Use keys to set the temperature set
point.
 Setting method: While in any function mode, press the key to select the desired function and use keys to change the
settings. Press
key to save the changes.
 The flow chart below shows how to switch the settings and internal functions:
Regulation Mode Operation Mode
Initial Setting Mode
Press key less than 3 sec
Press key
Press key more than 3 sec
Press key
