Delta DVP-ES3 Series User Manual

DVP-ES3 Series Operation Manual
5-40
_5
5.3.5 DVP04TC-E2 Control Registers
CR#
Attrib.
Register content
Description
0 O R Model name
Set up by the system:
DVP04TC-E2 model code = H’0083
1
O
R
Firmware version
Display the current firmware version in hex.
2
O
R/W
CH1 Input mode setting
Input mode: Default = H’0000. Take CH1 for example:
Mode 0 (H’0000): J-type (-100°C ~1,150°C)
Mode 1 (H’0001): K-type (-100°C ~ 1,350°C)
Mode 2 (H’0002): R-type (0°C ~ 1,750°C)
Mode 3 (H’0003): S-type (0°C ~ 1,750°C)
Mode 4 (H’0004): T-type (-150°C ~ 390°C)
Mode 5 (H’0005): E-type (-150°C ~ 980°C)
Mode 6 (H’0006): N-type (-150°C ~ 1,280°C)
Mode 7 (H’0007): -80mV~+80mV
Mode -1(H’FFFF): Close
3
O
R/W
CH2 Input mode setting
4 O R/W CH3 Input mode setting
5 O R/W CH4 Input mode setting
7 O R/W Temperature unit setting
Select the temperature unit (Celsius °C / Fahrenheit °F). Default =
H0(°C)
8
O
R/W
CH1 sampling range
Set sampling range at CH1 ~ CH4
Range = K1 ~ K100
Default = K10
9
O
R/W
CH2 sampling range
10
O
R/W
CH3 sampling range
11
O
R/W
CH4 sampling range
12 X R
Average temperature measured at
CH1
Average temperature measured at CH1 ~ Ch2
Temperature unit: set in CR#7
13 X R
Average temperature measured at
CH2
14 X R
Average temperature measured at
CH3
Average temperature measured at CH3 ~ Ch4
Temperature unit: set in CR#7
15 X R
Average temperature measured at
CH4
20 X R
Present temperature measured at
CH1
Present temperature measured at CH1 ~ CH4
Temperature unit: set in CR#7
21 X R
Present temperature measured at
CH2
22 X R
Present temperature measured at
CH3
23 X R
Present temperature measured at
CH4
28
O
R/W
Adjusted Offset value of CH1
Set the adjusted Offset value of Ch1 ~ Ch4. Default = K0
Range: K-400 ~ K400
Temperature unit: set in CR#7
Definition of Offset at Ch1 ~ Ch4 in DVP04TC-E2: Deviation digital
value from the target value.
29
O
R/W
Adjusted Offset value of CH2
30
O
R/W
Adjusted Offset value of CH3
31 O R/W Adjusted Offset value of CH4
40 O R/W
Function: Set value changing
prohibited
Prohibit set value changing in CH1 ~ CH4
41
X
R/W
Function: Save all the set values
Save all the set values, Default =H’0000
43 X R Error status
Register for storing all error status. See the table of error status for
more information.
100 O R/W
Function: Enable / Disable limit
detection
Upper and lower bound detection, b0~b3 corresponds to CH1 ~
CH4 (0: Disable/ 1: Enable). Default= H’0000.
