Delta DVP-ES3 Series User Manual

DVP-ES3 Series Operation Manual
5-42
_5
CR
Attrib.
Register content
Description
132
152
172
192
X
R
Output width (ms)
Width of control output. Unit: ms
133
153
173
193
X
R
Output cycle (ms)
Cycle of control output. Unit: ms
134
154
174
194
X
R
Output volume
Output volume
135
155
175
195
X
R/W
PID_RUN/STOP
0: STOP, 1: RUN. Default = K0
136
156
176
196
X
R/W
Auto-tuning
0: Disabled, 1: Auto-tuning. Default = K0
Symbols:
O: Set value will be saved.
X: Set value will not be saved.
R: You can use FROM instruction to read data.
W: You can use TO instruction to write data.
 Adjust PT Conversion Curve
You can adjust the conversion curves according to the actual needs by changing the Offset value (CR#28 ~ CR#31).
Offset: The corresponding voltage/current input value when the digital output value = 0.
 Mode0 ~ Mode6: output unit 0.1°








−
°
°
= Offset
X
Y
)(.
)(
10
Y= Digital output,
X= Measured temperature input
 Mode7: 0.01 mV = 80 mV/8000








−= Of
fset
V
V
X
Y
)m(.
)m(
010
Y= Digital output,
X= Current input
Mode 0 of CR#2~ CR#5
-100°C ~ 1150°C (-1000~11500)
-148°F ~ 2102°F (-1480~21020)
Mode 1 of CR#2~ CR#5
-100°C ~ 1350°C (-1000~13500)
-148°F ~ 2462°F (-1480~24620)
Mode 2, 3 of CR#2~ CR#5
0°C ~ 1750°C (0~17500)
32°F ~ 3182°F (320~31820)
Mode 4 of CR#2~ CR#5
-150°C ~ 390°C (-1500~3900)
-238°F ~ 734°F (-2380~7340)
Mode 5 of CR#2~ CR#5
-150°C ~ 980°C (-1500~9800)
-238°F ~ 1796°F (-2380~17960)
Mode 6 of CR#2~ CR#5
-150°C ~ 1280°C (-1500~12800)
-238°F ~ 2336°F (-2380~23360)
Offset (CR#34 ~ CR#37)
Deviation digital value corresponds to 0°C/ °F
