Delta H2.5 - Page 16

Please ensure the spacing requirement to allow for sufficient convective cooling.
It is essential to ensure sufficient space for product operation as shown in Figure 4-3.
Figure 4-3 : Adequate installation gap
>30cm
>50cm
>30cm
>50cm
>50cm
>30cm
>30cm
>30cm
>30cm
>30cm
>50cm
>10cm
>10cm
>10cm
Single inverter
Plural inverters
with BX6.3_AC system
>10 cm
>10cm >10 cm
16
Installation
