Fig. 39
Fig. 40
C
E
F
G
D
Use only cross-cutting saw blades. Use carbide-tipped blades with a negative hook angle. Do not
use blades with deep gullets that can deflect and contact the guard. Use only 10" diameter saw
blades which are rated for 5200 rpm or higher and have 5/8" diameter arbor holes.
Fig. 37
Fig. 38
A
B
CHANGING THE BLADE
MAINTENANCE
Disconnect machine from power source.
Fig. 36A
Fig. 36B
E
B
D
C
6. Fig. 36A illustrates the two outside corner pieces (B) and (E)
7. Fig. 36B illustrates the two inside corner pieces (C), and (D).
15
