Page #262 background imageLoading...
Page #262 background image
Chapter 11 Summary of Parameter SettingsMS300
253
11 Advanced Parameters
Pr.
Explanation
Settings
Default
11-00
System Control
bit 0: Auto-tuning for ASR and APR
bit 3: Dead time compensation closed
bit 7: Save or do not save the frequency
0
11-01
Per-Unit of System Inertia
1–65535 (256 = 1 PU)
256
11-02
ASR1ASR2 Switch
Frequency
5.00–599.00 Hz
7.00
11-03
ASR1 Low-Speed
Bandwidth
1–40 Hz
Read only
11-04
ASR2 High-Speed
Bandwidth
1–40 Hz
Read only
11-05
Zero-Speed Bandwidth
1–40 Hz
Read only
11-06
ASR1 Gain
0–40 Hz
10
11-07
ASR1 Integral Time
0.000–10.000 sec.
0.100
11-08
ASR2 Gain
0–40 Hz
10
11-09
ASR2 Integral Time
0.000–10.000 sec.
0.100
11-10
ASR Gain of Zero Speed
0–40 Hz
10
11-11
ASR Integral Time of Zero
Speed
0.000–10.000 sec.
0.100
11-12
Gain for ASR Speed Feed
Forward
0–200%
0
11-13
PDFF Gain Value
0–200%
30
11-14
ASR Output Low Pass
Filter Time
0.000–0.350 sec.
0.008
11-15
Notch Filter Depth
0–20 dB
0
11-16
Notch Filter Frequency
0.00–200.00 Hz
0.00
11-17
Forward Motor Torque Limit
0–500%
500
11-18
Forward Regenerative
Torque Limit
0–500%
500
11-19
Reverse Motor Torque Limit
0–500%
500
11-20
Reverse Regenerative
Torque Limit
0–500%
500
11-21
Flux Weakening Curve for
Motor 1 Gain Value
0–200%
90
11-22
Flux Weakening Curve for
Motor 2 Gain Value
0–200%
90
11-23
Flux Weakening Area
Speed Response
0–150%
65
