RMC70 Startup Guide
14 Delta Computer Systems, Inc.
5. In the Command Tool, in the axis the actuator is connected to,
click the button.
6. Browse to Motion Commands,
then Open Loop.
Choose the Direct Output
command and click OK.
7. For the Direct Output command
parameters, enter the following:
• Output: 0.1
• Ramp Rate: 100
When you send the command in the
next step, the Control Output voltage
will ramp to 0.1 V at a rate of 100
V/sec.
To Next Page
