Appendix A: Wiring
This appendix describes how to wire the RMC. Use the table below to
find the wiring diagram you need. For expansion module wiring,
consult the wiring diagram you received with it, or use the RMCTools
help. For communications wiring, consult the RMCTools help.
Note: Remove power from the RMC before connecting any wires.
Wiring Topic
Page
General Wiring Information
29
Power
30
MA Modules
Control Output, Enable Output, Fault Input
31
SSI Transducer
32
Start/Stop or PWM Transducer
34
AA Modules
Control Output, Enable Output, Fault Input
31
Voltage Feedback Transducer
37
Potentiometer
38
Current Feedback Transducer
38
QA Modules
Control Output, Enable Output, Fault Input
31
Quadrature Encoder (A, B, Z)
40
