Step 9: Test Feedback Device
Now that you have connected and tested an actuator, you will connect
and verify a feedback device. The device must already have been
wired to the RMC.
Configure Feedback
In Axis Tools, in the Axis Parameters pane, on the Setup tab, you will
configure certain parameters depending on the type of input you are
using.
Refer to the procedure for your module and transducer type:
Module
Transducer Type
Page
MA1 or MA2
MDT (Start/Stop or PWM)
17
SSI
17
AA1 or AA2
Analog (±10 V or 4-20 mA)
18
QA1 or QA2
Quadrature (Encoder A, B, Z)
18
AP2 or A2
Analog (±10 V or 4-20 mA)
18
Q1
Quadrature (Encoder A, B, Z)
18
