Delta RPI H3A User Manual

46
Model RPI H3A RPI H4A RPI H5A
Maximum output over
current protection
16A 20A 32A
AC OUTPUT (Grid side)
Current (inrush) (A, peak
and duration)
30A peak, 1ms.
Frequency 50/60Hz
Total harmonic distortion
<3% @ Rated power(#1)
Power factor >0.99@Rated power(#1)
Peak efficiency 97.50% 97.50% 97.50%
EU efficiency 96.80% 97.00% 96.80%
Output connection IP 67 single-phase
Fuse Internal fuse,
20A/ 250V*2
Internal fuse,
20A/ 250V*2
Internal fuse,
20A/ 250V*2
MECHANICAL
Housing Die cast
Cooling convection cooling
IP rating IP65
External communication
2 x RS-485 connection
Weight 21 kg
Dimensions 414.3 × 475.3 × 155 mm
REGULATIONS & DIRECTIVES
Safety
IEC 62109-1 / -2
AS 3100
CE compliance
Grid interface
VDE AR-N 4105
AS 4777
Emission IEC 61000-6-4, IEC 61000-6-3
Harmonics EN 61000-3-12
Variations and flicker EN 61000-3-11
Immunity EN 61000-6-2
Immunity
ESD IEC 61000-4-2
RS IEC 61000-4-3
EFT IEC 61000-4-4
Surge IEC 61000-4-5
CS IEC 61000-4-6
PFMF IEC 61000-4-8
#1: reactive power control disabled
