Delta RPI H3A User Manual

49
Pin Function
1 Digital input 1
2 Digital input 2
3 Digital input 3
4 Digital input 4
5 Output 1
6 Output 2
Country =Italy LV/SPI
Function D1 D2 D3 D4 Output 1
Output 2
No function 0 0 0 0 1 1
Remote off 1# 0# 0 0 1 1
Narrow
frequency limit.
0 1 0 0 1 1
#1: Relay is closed, 0: Relay is open.
Country = Germany
Function D1 D2 D3 D4 Output 1 Output 2
No function 0 0 0 0 1 1
Active power =
0%
1# 0# 0 0 1 1
Active power =
30%.
0 1 0 0 1 1
Active power =
60%
0 0 1 0 1 1
Active power =
100%
0 0 0 1 1 1
#1: Relay is closed, 0: Relay is open.
